378-8507: HYDRAULIC OIL FILTER BASE, 3788507

Cat® Hydraulic Oil Filter Base for use on Off-Highway Truck, L X W X H: 404 X 130 X 129mm

Description:

378-8507 is a hydraulic oil filter base used to provide means for securing oil lines to oil filters that mount to the engine.

Cat oil filters help prevent damage to your lubrication system by filtering out the contaminants that impact performance.

Attributes:

• Cast iron oil filter base with hardware
• Filter Type: Cartridge
• Inlet Port Size: -20 Flange Port
• Outlet Port Size: -20 Flange Port
• Differential Pressure Switch Port Thread Size: 9/16-18
• Length: 404mm (15.9 in)
• Width: 130mm (5.1 in)
• Height: 129mm (5.1 in)

Application:

Consult your owner’s manual or contact your local Cat dealer for more information.

Specifications:

• Height (in): 5.1
• Length (in): 15.9
• Material: Cast Iron
• Thread Size (in): 9/16-18
• Width (in): 5.1
