340-1456: AIR CLEANER PLENUM, 3401456

Cat® Air Cleaner Plenum, Inlet Diameter: 203.6 mm

Description:

Cat air cleaner plenums such as 340-1456 transfer air and create an airtight seal between the pre-cleaner and air cleaner system, ensuring that contaminated air cannot enter the system between stages.

Attributes:

• Polyethylene air cleaner plenum
• Inlet Inner Diameter: 198 mm (7.8 inch)
• Outlet Length (Inside): 419 mm (16.5 inch)
• Outlet Width (Inside): 117 mm (4.6 inch)
• Dust Ejector Diameter: 90 mm (3.5 inch)
• 4-bolt mount for use with M8 hardware
• SAE -8 O-Ring Port (3/4-16) for sensor attachment

Application:

For use on certain Wheel Loader models. Consult your owner's manual or contact your local Cat Dealer for more information.

Specifications:

• Material: Polyethylene
• Color: Black
• Inside Diameter (in): 7.8 (Inlet)
• Length (in): 16.5 (Outlet)
• Width (in): 4.6 (Outlet)
• Overall Length (in): 16.8
• Overall Width (in): Not Specified
• Overall Height (in): Not Specified
