224-9476: AIR CLEANER, 2249476

Cat® Air Cleaner, Axial and Radial Seal Element Design, In-Line Flow, Length: 369 mm

Description:

244-9476 is an air cleaner with primary and secondary filter elements.

Cat Air Cleaners are your best value for normal duty applications, delivering increased engine protection and preventing equipment downtime. Offering a long service life and exceptional filtration, Cat Air Filters are also environmentally friendly and cost effective. Designed to the exact specifications of your Cat equipment, genuine Cat Filters are a crucial factor in your machine’s ability to use air efficiently. A clean filter element protects internal mechanisms from being damaged by dirt.

Choosing Cat Air Cleaners is a cost-effective way to protect your equipment. Consistently choosing Cat Air Filters is the best choice to ensure long life and optimum performance of your Cat machinery.

Attributes:

• Fiberglass reinforced plastic housing
• 30% glass filled nylon filter elements
• Axial seal primary filter element and radial seal secondary filter element
• In-line airflow design
• 2-bolt mount for use with M8x1.25 mounting hardware
• Scavenge Outlet Diameter: 40 mm (1.6 inch)
• Inlet Width: 157 mm (6.2 inch)
• Inlet Height: 230 mm (9.1 inch)
• Outlet Diameter: 89 mm (3.50 inch)

Application:

For use on certain Track-Type Tractor models. Consult your owner's manual or contact your local Cat Dealer for more information.

Specifications:

• Material: Plastic (Housing); Nylon (Filter)
• Type: Air Cleaner
• Overall Length (in): 14.5
• Overall Width (in): 8.2
• Overall Height (in): 9.5
