380-8484: HYDRAULIC SCREEN (FILTER), 3808484

Cat® In-Tank Return Hydraulic Screen (Filter), OD X L: 60 X 271mm

Description:

Part # 380-8484 is a 125 micron in-tank return screen (filter) that threads onto the tank to filter hydraulic oil.

Attributes:

• Material: Plated steel with stainless steel inner screen
• 125 micron
•  Flow Rate: 500 L/min
• Mounting Thread: 2-1/2-12
•  Connection: SAE -16 STOR Port, 1-5/16-12
• Length: 271mm (10.67 in)
• Diameter: 60mm (2.36 in)
•  Hex size: 70mm (in)

Application:

Consult your owner’s manual or contact your local Cat dealer for more information

Specifications:
